Multi-functions Filtering + Washing + Drying (three in one) Machine

Multi-functions filtering, washing, drying (three in one) machine is a solid-liquid equipment with the functions of filtration, washing, drying reaction and residue discharging automatically. It is widely used in fine chemical, petroleum food stuff, printing pharmaceutical industries and so on.

Functions

Filtration: operate under pressure or vacuum to realize solid-liquid separation. During filtration, the filter cake is flat and the solid-liquid separation effect is good.

Washing: a 360°rotary spray device is installed on the inner side of the container to make the cleaning (washing) liquid evenly distributed in the container, which can realize the internal cleaning of the container and slurry washing of materials. The filter cake and washing solution are mixed by lifting and stirring, so that the slurry crystallization and filter cake can be fully washed without crystal breaking.

Drying: the filter cake is scraped loose layer by layer by stirring leaves, the equipment heating device uniformly heats the filter cake, and heats the wet material with hot gas under vacuum to accelerate evaporation, so as to achieve the purpose of rapid and sufficient drying.

Sampling: after the filter cake is dried for an appropriate time, online sampling is carried out to analyze the moisture content of the filter cake, which can be cooled and prepared for unloading when it meets the internal quality control requirements of the product.

Unloading: scrape the material loose and discharge it automatically from the discharge port on the side of the tank wall by pushing the mixing paddle.

Features

1. Fully enclosed filter, no leakage, no pollution.
2. Solid-liquid separation can be realized under pressure or vacuum state. Filter cakes are evenly distributed when filtering which can get good effect.
3. Stirring system can stepless speed regulating and multi-function work. It can enlarge furthest for the cake space, thus filter cake can be fully cleaned. The time of drying is reduced greatly, with high efficiency.
4. Discharge valve can discharge automatically which can lower labor intensity.
5. Especially suitable for the material that has large solid content, and recovering liquid phase and solid phase respectively.
6. Adopting horizontal placing filter material, one time completely filtering no remains. Filter material has unique sealing structure which is easy to be changed.
7. Anticorrosion three in one system is made of special material which can be suitable for multiform anticorrosion medium.
8. Stirring, mixing, beating, reacting, washing and multiform process working can be practiced in the body and it can carry out full automatic control.

Any requirements, contact us now!
